Horizontal flowrappers SEH 025BB
OVERVIEW
• Electronic continuous box motion Horizontal Wrapping Machine
• Specific machine for modifed atmosphere packaging thanks to the tight packs granted by this sealing system
• Options: Automatic splicer, electrical photocell for printing registration, modifed atmosphere, coder, powered feed roll, gusseting devices, pack defating devices, no product / no bag, out of position, no cut, stop of jaws closing for out of phase product, easy opening package, outfeed packs control, outfeed conveyor extension, stainless steel version
MAIN FEATURES
• Product dimensions:
• Width: max 350 mm / 13,78’’
• Height: max 180 mm / 7,09”
• Reel dimensions:
• Reel width: 520 mm / 20,47”
• Outside diameter: max 350 mm / 13,78’’
• Core diameter: 70 ÷ 76 mm / 2,76’’ – 2,99’’
• Machine dimensions: 5960 x 1350 x 1610 mm
234,65” x 53,15” x 63,39”
• Weight: 1300 kg
• Packaging materials: heat-sealable, coated, cold-sealable, polyethylene
For heavy or adhesive products
UP TO 50 PPM/MIN
Additional information
Machine rate | |
---|---|
Final packaging | |
Your product | Bakery, Chocolate factory, Frozen products, Fruits & Vegetables, Meat, Non-food product, Pastry |
