American box closer ETCA CS1000

• Hot-melt gluing

• Change of size by flywhells in 2 minutes time

• The side belts keep the case perfect under control during closing the top of the case.

• Transit control; when case crashes the machine will stop (time control)

• Control minimum distance between cases 350 mm

• Dimensions machine : 2000 x 1350 x 2000 mm

78,74” x 53,15” x 78,74”

• Pneumatic supply : 6 bars

• Mini/maxi cases dimensions:

• Length: 200 – 500 mm / 7,87” – 19,69”

• Width: 150 – 510 mm / 5,91” – 20,08”

• Height: 120 – 500 mm / 4,72” – 19,69”
